Page 20 - 2025中文型錄

工作檯及接地 解決方案

Bench Top Laminates(工作檯層板)
Product Code : DY1008

材料：防靜電木層板（多種顏色）

Nevamar 的靜電耗散層合板的獨特特性使其非常適合
於各種靜電敏感的應用。此產品滿足或超過電性能的
所有標準，即使在低濕度空間。該產品不會產生表面
脫落，是一個可持久的工作表面的防靜電材料。

Static Dissipative Veneer (防靜電貼面)
Product Code : DY1008

材料：防靜電貼面（綠/灰) Electrical Properties
Top Surface Resistance < 1 x 10 Ω
8
5
該產品提供 ESD 防護工作桌面,適用於 ESD 敏感產 Bottom Surface Resistance < 1 x 10 Ω
品。易於安裝於工作桌相關 ESD 防護區應用。 Volume Resistance < 1 x 10 Ω
7
Static Decay ( + 1000V to 0V) < 0.7 seconds
Tribrocharging Voltage < 40V
Part Number:
DY1008-VENEER, Green, 1.2MX20MX0.7MM Physical Properties
DY1008-VENEER, GREY, 1.2MX20MX0.7MM Material PS, EVA, PE (Synthesized)
Width 1.2 Meters

Length 20 Meters
Thickness 0.7 mm
o
Minimum Tolerable Temperature -12 C Applicable to
o
Maximum Tolerable Temperature 100 C Indoor workshop

Benefits
Intrinsic Property The resistance readings of
the product is not humidity
and/or temperature
dependent
Permanent Property Static dissipative property
is permanent
Environment Friendly Non-toxic, odorless and
tasteless
Engineering & Chemical Abrasion, oil, acid (weak)
and alkaline resistant
Flexible Come in roll form, easy to
handle and to post-form

19
